EcoTech Marine Reef Lighting Guide: Radion & Mounting

Gradient composite featuring the EcoTech Marine Radion XR30 G6 Pro LED light, XR30 High Intensity Lens Kit, RMS XR15 Tank Mount System, and Multi-Light RMS Arm Kit

This guide covers the current G6 fixtures, the optics, the mounting systems and the controller bridge, and links every item to its product page. If you’re also looking at auto-dosing or monitoring equipment from the same ecosystem, our Neptune Systems Reef Controller & Auto-Dosing Guide covers the Apex platform, including the MXM Mobius module that bridges the two brands (more on that below).

Plan and shop

Setting up a marine tank? Choose fish only, soft coral and LPS, or SPS reef. The equipment list for your tank size follows.

Open the aquarium setup planner

The Radion G6 fixtures

EcoTech’s current flagship line is the Radion XR30 G6, available in two variants: the Radion XR30 G6 Pro and Radion XR30 G6 Blue, both built for larger or deeper reef tanks needing higher output. For smaller or shallower systems, the Radion XR15 G6 Pro and Radion XR15 G6 Blue scale the same core technology down to a more compact footprint suited to nano and mid-size tanks. The Pro and Blue naming across both sizes generally reflects a difference in spectrum tuning and channel mix rather than raw output, so the right choice comes down to which spectrum profile suits your coral mix rather than tank size alone. EcoTech describes the Pro as a balanced LED mix with spectrums similar to metal halide, and says the Pro is the light used in many public aquariums, aquaculture facilities and coral spawning labs. The Blue is tuned further toward blue, and the G6 adds 395 nm diodes for stronger fluorescence and lets you tune the blue between actinic and crisp.

Optics and spectrum shaping

The Radion Diffuser is made for the XR15 (G5 and G6) and softens and spreads the point-source light output, reducing the “disco ball” shimmer and hot-spotting that can otherwise show up under a Radion, particularly useful in shallower tanks where the light source sits closer to the water surface. On the opposite end, High Intensity Lens Kits are available for both the XR30 and XR15 lines, narrowing the beam angle to push more usable light deeper into taller tanks at the cost of a slightly smaller lit footprint per fixture. The XR30 High Intensity Lens Kit and the XR15 High Intensity Lens Kit each add one lens that narrows the beam to raise PAR over a smaller area, and EcoTech says the XR30 kit fits G5 and G6 fixtures. EcoTech says the diffuser costs around 20 percent of light output, and suggests raising the LED power to make up the loss.

Mounting systems

EcoTech’s RMS (Radion Mounting System) range covers everything from single-fixture tank mounts to multi-light arm setups. The RMS XR15 G5 & G6 Tank Mount System and RMS XR30 Single Light Tank Mount System clamp directly to the tank rim for a single fixture without needing an overhead hanging point, which matters if you don’t have ceiling or stand access for a hanging kit. For hobbyists running multiple fixtures over one tank, the Multi-Light RMS Arm Kit and RMS Slide for Radion XR15 let you position several lights independently along a shared rail rather than mounting each on its own separate arm. If you’d rather hang lights from above than clamp to the tank, the Radion Single Light Hanging Kit (6ft) and RMS Rail Hanging Kit XR717 cover single-fixture and rail-based multi-fixture hanging setups respectively. Product pages: RMS XR15 G5 & G6 Tank Mount System, RMS XR30 Single Light Tank Mount System, Multi-Light RMS Arm Kit, RMS Slide for Radion XR15, Radion Single Light Hanging Kit and RMS Rail Hanging Kit (XR717).

What a multi-light rail system needs

EcoTech sells the Multi-Light RMS in parts, and the arm kit alone is not a working system. It needs three components: the track, which spans the arms; the arm kit, which mounts to the tank and holds the track; and a slide for each light, which clamps the Radion to the track. One track can carry XR15 and XR30 lights together, and EcoTech says the Multi-Light RMS mounts the lights about 7 inches (18 cm) above the tank and fits trim up to 1 3/8 inches thick.

The track comes in lengths matched to tank width.

TrackFor tanks this wide
40.5 inch38.5 to 48.5 inches
50.5 inch48.5 to 58.5 inches
60.5 inch58.5 to 68.5 inches
70.5 inch68.5 to 78.5 inches
80.5 inch78.5 to 88.5 inches

EcoTech also makes 20.5 and 30.5 inch tracks for tanks from 18.5 to 38.5 inches wide.

The single-arm XR30 tank mount clamps to a tank rim or trim up to 1 3/8 inches thick and needs about 13 inches of clearance above it.

Bridging to Neptune Apex control

If you’re already running or planning a Neptune Apex controller, the Neptune MXM Mobius Wireless Control Module is worth knowing about specifically because it’s a cross-brand bridge rather than an EcoTech product: it lets an Apex system communicate with EcoTech’s ecosystem (Radion lighting and VorTech-family pumps) over EcoTech’s own wireless protocol, so lighting schedules and pump behavior can respond to Apex sensor data rather than running as two separate, uncoordinated systems. The MXM Mobius Wireless Control Module needs a Neptune Apex A2 or A3 system, and the product page lists it as controlling up to 25 Mobius devices. Its compatibility list covers the Radion XR15 and XR30 (G5 and G6), the VorTech MQD pumps (MP10, MP40, MP60) and the Vectra Series 2 return pumps, plus several AquaIllumination lights. Our Neptune Systems guide covers the rest of the Apex ecosystem it connects to.

XR30 G6 and XR15 G6 side by side

These figures are from the specifications on the product pages for the Pro and Blue fixtures.

Radion XR30 G6Radion XR15 G6
Size (L x W x H)11.8 x 7 x 1.5 inches7 x 7 x 1.5 inches
Weight4.5 lb (1.98 kg)3.5 lb (1.58 kg)
Maximum power215 W95 W
Recommended mounting height8 to 10 inches (about 20 to 25 cm)8 to 10 inches (about 20 to 25 cm)
Cable length13 ft13 ft
Mounting optionsRMS arm, RMS track, hanging kitRMS arm, RMS track, hanging kit
ControlMobius appMobius app

EcoTech quotes a 126.3 degree spread for the G6 optic and says one XR30 G6 gives even PAR across almost four feet of coverage area. Those are the company’s figures for the fixture on its own, so treat the four feet as an upper bound and not a promise for your layout. EcoTech says the Mobius app controls the fixture without a separate controller.

Quick reference

NeedProduct
Larger or deeper tank lightingRadion XR30 G6 Pro or Blue
Nano or mid-size tank lightingRadion XR15 G6 Pro or Blue
Reduce shimmer and hot-spotting (XR15)Radion Diffuser
Push light deeper into tall tanksXR30 or XR15 High Intensity Lens Kit
Single-fixture rim mountRMS XR15 G5 & G6 or RMS XR30 Tank Mount System
Multi-fixture rail mountMulti-Light RMS Arm Kit, a track for your tank width, and RMS Slide for Radion XR15
Hanging mount (single or multi)Radion Single Light Hanging Kit or RMS Rail Hanging Kit (XR717)
Bridge to Neptune ApexNeptune MXM Mobius Wireless Control Module

Planning a Radion purchase

If you’re mapping out a Radion-based lighting upgrade, decide fixture size and mounting style together rather than in sequence. A rail-based multi-light arm kit needs different tank clearance than a single hanging kit, so it’s easier to plan both from the start than to retrofit a mounting change after a fixture is already installed. Measure your tank before you pick a track: the track length depends on the tank width, and the single-arm mounts clamp onto a rim or trim up to 1 3/8 inches thick.

FAQ

How high should I mount a Radion?

EcoTech recommends 8 to 10 inches (about 20 to 25 cm) for both the XR30 G6 and the XR15 G6. If you need to mount higher, EcoTech designed the High Intensity Lens Kit for deep tanks and for fixtures mounted higher than usual.

Do I need a controller for a Radion?

No. EcoTech says Mobius app control needs no separate controller purchase. A Neptune Apex only comes into it if you want one app (Apex Fusion) for your lights and pumps, through the MXM module.

Does the diffuser fit the XR30?

The Radion Diffuser product page lists the XR15 G5 and G6 only. The page also notes that, because of the adapter plate, it does not work with earlier Radion generations.
